Windmill Blade Adapter Price: 120000USD
The windmill blade transport adaptor is specifically designed for transporting wind turbine blades. Windmill rotor blade adapter features a high strength frame and a retractable structure to ensure safe and stable transport. Primarily used for long distance handling and loading or unloading of large blades in wind power projects, windmill rotor blade trailer adapts to different sizes and transport environments.
Specification of Windmill Rotor Blade Trailer
Dimension: 19500mm*3400mm*4650mm
Applicable blade: 56.5m-76m
Axle: 4 lines 8 axles
Tires: 32 units
Max rotation angle: 360°
Hydraulic station: 40KW Four-cylinder Diesel Engine
Tail: Slewing support cylinder with tooling at the tail (horizontally telescopic); with pusher
Transportable wind blade specification: 121-155 model
Diameter of lifting cylinder: 320mm
Advantages of Windmill Rotor Blade Adapter
The windmill rotor blade lifter trailer exhibits high reliability and efficient adaptability, handling long distance, cross regional transport and transfer operations in complex terrains such as mountains and hills with ease.
The core of the windmill blade adapters utilizes a detachable and modular structure, allowing for quick adjustments to the vehicle configuration to accommodate wind turbine blades of different sizes and weights without requiring replacement of the entire transport equipment, significantly reducing equipment investment and time costs.
The windmill blade transport adaptor's frame is constructed from a high strength, wear resistant alloy and undergoes multiple stress strengthening treatments. This increases the load bearing capacity while effectively controlling the windmill rotor blade adapter's weight, optimizing fuel economy and adapting to local road load standards, achieving a balance between practicality and economy.
The windmill rotor blade trailer's powertrain boasts powerful output and adaptability. Windmill rotor blade lifter trailer's customized high power engine and high precision gearbox form a perfect ratio, adjusting power output in real time according to road conditions, maintaining stable operation even when fully loaded uphill or on muddy roads.
The windmill blade adapters' hydraulic control system uses military grade core components and has undergone rigorous environmental testing. When driving the wind turbine to perform lifting and rotation movements, it not only responds swiftly but also achieves precise control, fundamentally preventing hidden damage to the wind turbine caused by sudden power changes.
The windmill blade transport adaptor's load bearing and protection system design emphasizes humanization and safety. The low profile load bearing surface is treated with a non slip, wear resistant coating, and multiple sets of retractable special fixing clamps can achieve all around locking for wind turbines of different curvatures, preventing displacement during transportation.
Key parts of the windmill rotor blade adapter's body are equipped with multi-stage hydraulic buffer mechanisms that automatically adjust the buffering force according to the amplitude of bumps, minimizing the impact of vibration on the wind turbine.
The windmill rotor blade trailer's control system integrates intelligent steering assist and anti-rollover monitoring functions. It can automatically correct the windmill rotor blade lifter trailer's posture when turning and quickly trigger warnings and assist braking in case of emergencies, thus building a comprehensive safety protection system.
